This product is only suitable for healthy and skilled
swimmers over 16 years of age.
This product is not suitable for use by people with
pacemakers, as there may be a risk of interference from
the motor and shark guard (if fitted).
This product is micro-positive buoyancy. In the water
off the hands will float to the surface in time.
914mm(L)×530mm(W)×330mm(H)
23KG
Press the L + R simultaneously for 5s, the screen will
display “ALTIVS”.
Select TR to enter shutdown page, press R when the
screen displays “POWER OFF”.
After turning it on, press L+R for 3s in the Home page
to enter Menu page, and then press TL and TR to adjust
the speed. If any of handles are released, the motor will
stop.
Yes.
Geomagnetic declination setting, depth warning
setting, turn back battery reminder, use time, etc.
None.
923Wh
NO, it is not allowed to remove the battery for charging
or transporting. Only the Sublue authorized technicians
can remove the battery.
Ordinary charger: 3h
Fast charger: 2h
Input voltage: 110V-240VAC
Charging voltage: 51V DC
①Please charge in a cool,dry and ventilated
environment and use Sublue authorized devices.
②Please ensure that ALTIVS is in contact with the
ground when charging. Otherwise, the electrical charges
will gather on the shell of ALTIVS, leading to the risk
of electrical shock, especially in wet or saltwater
environments.
About 60mins
There are 4 speed modes, the fastest speed is 16km/h.
Many factors can affect its speed, including the user's
own condition, water temperature, depth, current,
environment, and other devices used with ALTIVS.
Go to the Home page, and use L/R to adjust speed.
No.
The screen will display error codes when there is a
problem with ALTIVS. Please contact your dealer or
ALTIVS headquarters directly if you encounter this
situation.
①Please clean ALTIVS with freshwater after use. Place
it nose down tilt upwards, and then place the freshwater
house in rear outlets and flush out debris for at least
2mins.
②Do not use abrasives, alcohol-based or acid-based
cleaning products to clean ALTIVS, use freshwater with
a little detergent or car wash solution with a soft damp
cloth.
If the product is not to be used for a long period of time,
please store it in accordance with the following
principles:
①Use the original ALTIVS packaging supplied with the
unit to store ALTIVS when not in use. Ensure the
drainage plug has been removed from the base of the
packing box. Ensure ALTIVS is thoroughly drained and
allow to dry thoroughly before transporting or putting
into storage.
②For long-term storage, recharge the batteries
regularly.
③For ambient storage temperatures under 25℃,
charge once every 3 months, for ambient storage
temperature over 25℃, charge once every 2 months.
④Do not leave ALTIVS in direct sunlight for prolonged
periods.The surface temperature of the ALTIVS
bodywork may cause burns in hot environments.
Sustained heat may also shorten the life of your battery
or cause them to malfunction. Please store in a shaded
area and use the reflective cover when shade is not
available.
ALTIVS' lithium ion battery contain flammable, toxic
and corrosive materials.In case of misuse or inadequate
care they are liable to combust or explode causing
injury or risk to property. Please follow the following
guidelines carefully.
①Do not remove battery from ALTIVS units. Only
ALTIVS trained and authorized technicians should
disassemble or disconnect battery from the ALTIVS.
②If the aluminum casing for the battery shows signs of
deformation, dents, corrosion or cracks, or if battery is
emitting strange odour or noise do not use the ALTIVS
unit.
③For more information on battery itself, safety and
care with Li-ion technology, please visit your nearest
ALTIVS service centre or contact ALTIVS HQ.
